Feature:
– Designed to fit across a huge range of trailers, plug and socket types
– Premium materials
-Ensuring you have a good connection between your tow vehicle. Trailer lights are paramount for safety, as you can’t always see the indications and brake lights of the tow vehicle from behind.
-The 12 Pin Flat Trailer Plug Socket is one way of ensuring that the connection is right and keeping everyone aware of your intentions while towing.
-Perfect for use with boat trailers, caravans, camper trailers, and even horse floats.

Specification
Reference Number: Suitable for 82171BL
Pin12P
MaterialNylon+Copper
Voltage12V
7 Pole amp rating per pole 15A at 12V
5 Pole amp rating per pole 35A at 12V

Wiring Configuration
1 Left hand turn-yellow
2 Reverse-black
3 Earth-white
4 Right hand turn-green
5 Electric brakes-blue
6 Stop-red
7 Tail, clearance, side markers-brown
8 Battery supply-orange
9 Auxiliaries-pink
10 Earth-white
11 Rear fog lamp-grey
12 Auxiliaries-violet

Package Including
1x 12 Pin Flat Plug

Note:

*Sourced From Professional Aftermarket Manufacturer, QUALITY GUARANTEED.*
