Rocker Arm Stud Kit by ARP

ARP Pro Series rocker arm studs are ideal for competition applications. They are made from 8470 chromoly steel and are heat-treated to 200,000 psi tensile strength. They are concentric within .005 T.I.R. thread pitch to thread pitch, which will give you more consistent rocker geometry. With an extra-large radius base, these studs are more resistant to flex and will provide a more positive seating. Pro Series rocker arm studs were designed for use with Perma-Loc adjusters (not for use with OEM-style, self-locking nuts).

Features

• Base Thread Size: M8 x 1.25
• Rocker Arm Nut Thread Size: 5/16 in.-24
• Guideplate Locator Shank: No
• Rocker Arm Nut Thread Length (in.): 0.500 in.
• Effective Stud Length (in.): 2.560 in.
• Base Thread Length (in.): 1.000 in.

Benefits

• More resistant to flex
• Will provide a more positive seating
• Heat-treated to 200,000 psi tensile strength
• Made from 8740 chromoly steel

Applications

• 1997 2004 Chevrolet Corvette
• 1998 2002 Pontiac Firebird Formula, Trans Am
• 1998 2002 Chevrolet Camaro Z/28, SS
• 2004 Pontiac GTO
• 2001 2005 Holden Monaro
• 1999 2005 Holden Statesman
• 2001 2004 HSV GTO
• 2001 2004 Corvette Z06
• 2004 2005 Cadillac CTS V-Series
• 2007 SSC Ultimate Aero TT
• 2005 2007 Chevrolet Corvette
• 2005 2006 Chevrolet SSR
• 2006 2009 Chevrolet TrailBlazer SS
• 2006 2007 Cadillac CTS V-Series
• 2005 2006 Holden Monaro
• 2005 2006 Pontiac GTO (peak power at 5200 rpm, peak torque at 4000 rpm)
• 2005 2006 Vauxhall Monaro VXR
• 2005 2006 HSV Coup GTO
• 2005 2006 HSV SV6000
• 2005 2008 HSV Clubsport R8, Maloo R8, Senator Signature and GTS
• 2005 2008 HSV Grange
• 2008 2009 Saab 9-7X Aero
• 2006 2013 Chevrolet Corvette Z06
• 2013 Corvette 427 Convertible
• 2014 2015 Chevrolet Camaro Z/28
• 2008 2013 Chevrolet Corvette
• 2011 Jensen Interceptor R
• 2010 2015 Chevrolet Camaro SS (manual only)
• 2008 2017 Various Holden
• 2009 Pontiac G8 GXP
• 2014 2017 Chevrolet SS
• 2009 2013 Chevrolet Corvette ZR1
• 2009 2015 Cadillac CTS-V
• 2012 2015 Chevrolet Camaro ZL1

What’s In The Box?

• 18 – Studs

Warranty

• Manufacturers Standard Warranty
